Data Property

Navigation:  Reference Guide > Properties >

Data Property

Previous pageReturn to chapter overviewNext page

Sets the message to encode with the barcode control.



Property Data Type

BSTR





Remarks

The default value is "1234".

If the SymbologyType property is set to UCC/EAN128 (GS1-128), you could use a "FNC1" string to indicate the end of a varied-length data field. For example, set the "Data" property to "(01)12345678901234(10)12345FNC1(11)080101", "FNC1" is used to indicate the end of the data field after the Application Identifier (AI) #10, since AI #10 allows the corresponding data field to have 1-20 alphanumeric characters.

GS1_128
